Coral Reef Diagnostics

Chagos Archipelago - Salomons Island (BISA94)

Khaled bin Sultan Living Oceans Foundation — Global Reef Expedition
⬇ Download this page as a report card
05
Photo: Anderson Mayfield/Coral Reef Diagnostics
Survey date(s)
2015-04-25
Coordinates
-5.3504, 72.2200
Coral cover
52%
± 5.4% SE, n = 15 transects · Benthic surveys
Coral bleached
2.8%
Observations
None tagged; see Stressors below
Heat stress
Most recent heat load record
26 Oct 2026 · Bleaching Warning
5-year thermal stress load
5-year mean max. degree heating weeks (DHW)
2021–2025
i 5-year mean max. DHW is the mean of the annual maximum DHWs over the five complete years named above, not conditions today.
More infoChagos Archipelago, UK (NOAA CRW virtual station)
Photographs
2
Site summary

A lagoonal patch reef inside Salomon, leeward on Anderson's field sheet (dived to 18.6 m), where fleshy turf and macroalgae compete with a Porites- and Goniopora-dominated coral community, with Acropora almost completely absent. Coral falls from 63% in the shallowest stratum to about 11% on one deep transect, and Anderson's notes record many bleached corals in the shallows. Surveyed on the Living Oceans Foundation's Global Reef Expedition.

Max. depth dived
18.6 m
sample-sheet maximum
Water temp. during survey
29.9°Cii
Station CTD reading
+0.8°C vs the 2015 mean sea temperature (29.1°C)
ii Station CTD value (LOF station records), not a dive reading: the CTD cast at this station recorded 29.92°C (Living Oceans Foundation Chagos station records); the sheet's other entry, 39.78°C, is not a plausible sea temperature and is not used.
More infoAnderson's sampling-sheet note for the dive gives 30-31°C; the CTD cast is the station value shown.
Bottom time
63 min
in at 13:57

Seven independent survey stations shown with the program’s logo — click one to see how far it is from this site.

Eight other CRD dive sites with their own pages within 5 km shown in orange — click a marker to open its page.

Site description

Setting

BISA94 is a lagoonal patch reef inside Salomon atoll, leeward on Anderson's field sheet, surveyed 25 April 2015 on a dive to 18.6 m.

General benthic features

Bare substrate and invertebrates are both under 5%, so the benthos is essentially coral or fleshy algae. Across 28 genera the assemblage is massive- and fleshy-dominated: Porites 25% of the benthos, 48% of all coral, and Goniopora 13%, three-quarters of the coral between them, while Acropora is effectively absent at 0.1%.

Coral cover

Stressors

Published bleaching is 2.8% (CoralNet analysis of the survey images; Mayfield & Dempsey 2026, suppl. S1). Only two photographs exist from this dive, and neither shows crown-of-thorns or disease (e.g., Image 1, Image 2).

Anderson's field record describes the condition: all four Seriatopora hystrix sampled were 100% bleached, most P. acuta looked healthy though one was bleached, and the notes record many bleached corals in the shallows (see Dive record below). The Living Oceans Foundation transects here recorded no cyanobacteria and 0.1% recently dead coral.

Comparisons with other data

Apart from the Living Oceans Foundation survey shown here, we found no other surveys at this site as of 2026. Within 5 km, seven independent stations recorded station-year means of 6.8–63% hard coral cover between 2006 and 2020; the nearest, XL Catlin Seaview Survey at transect 36015, 0.66 km away, read 28% in 2015.

Dive record

Anderson's afternoon dive on 25 April 2015 entered the water at 13:57 and lasted 63 minutes, to a maximum depth of 18.6 m (the field sheet); Anderson's notes describe an incredibly murky lagoon site with terrible visibility, high coral cover in places on a Porites cylindrica framework from 15 to 18.5 m, calm, warm water, all Seriatopora bleached, most P. acuta looking okay though one was bleached, many bleached corals in the shallows, and no pocilloporids other than P. acuta. Anderson sampled seven Pocillopora acuta colonies (six confirmed by RFLP; CHPd129 by field call): CHPd128 (collected 14:05 at 18.5 m; small, healthy, under a year old), CHPd129 (14:12, 16.5 m; pale lemon yellow on P. cylindrica rubble, likely healthy), CHPd130 (14:33, 15.2 m; small, healthy, lemon yellow), CHPd131 (14:38, 10.9 m; a healthy adult with a bleached base), CHPd132 (14:43, 8.9 m; healthy, among many 100% bleached Seriatopora), CHPd133 (14:49, 11.8 m; 100% bleached), and CHPd134 (14:59, 5.7 m; very pale, partly dead). Anderson also sampled four Seriatopora hystrix colonies: ChSe138 (14:15, 14.5 m; a 100% bleached recruit on dead rubble), ChSe139 (14:20, 16.0 m; 100% bleached, in a crack in the rock), ChSe140 (14:23, 15.0 m; 100% bleached, half smothered by macroalgae, no live tissue evident), and ChSe141 (14:54, 10.4 m; green fluorescent, likely 100% bleached, no live tissue evident; no healthy seriatoporids were seen at the site). Pocillopora acuta colonies from this archipelago were analyzed in Thomas et al. (2026, Global Ecology and Biogeography 35:e70305, https://doi.org/10.1111/geb.70305).

Other notes

Aspect follows Anderson's field sheet (LOF fellowship 2016 workbook: 'lagoonal patch reef', 'leeward'); the expedition's 933-site table classes the station as 'protected' (patch reef). Esri World Imagery (no LOF habitat map covers Salomon atoll; the LOF Chagos habitat map covers only Peros Banhos) puts the pin among patch reefs in the south-west part of the Salomon lagoon, consistent with the sheet.

CV model comparison

Headline is the transect value; every other row is listed beside it for comparison and none is averaged in. ⚠ The reference here is NOT the same instrument as at Mauritius, Oman, Kenya, or the Red Sea.
More infoThose are point counts on the photographs; this is a diver swimming a transect. The models and the reference never saw the same thing. ⚠ SITE-LEVEL ONLY. None of the Chagos photographs (2,500 frames across all stations) can be matched to a transect taken within 200 m, so transect-vs-image comparisons use site means, never individual frames. The transect value is the mean of all of this station's own transects in the expedition's per-transect benthic data. The transect is THE coral-cover value for this site and stands alone. The rows below it are a methods comparison only: no computer-vision value is averaged with it, feeds the headline, or carries over to the site's cover figure.
MethodHard coral cover (%)Photos (n) ± SE
Transect mean (all transects)52.0
CoralNettoo few photos (n=2)
In-house DINOv3too few photos (n=2)
CoralSCOP editedtoo few photos (n=2)
Claudetoo few photos (n=2)

CoralNet: this method was run on 2 of 2 photos, under the 10 needed for a value, so it is not shown and is left out of any mean; every other row rests on its own photo count.

In-house DINOv3: this method was run on 2 of 2 photos, under the 10 needed for a value, so it is not shown and is left out of any mean; every other row rests on its own photo count.

CoralSCOP edited: this method was run on 2 of 2 photos, under the 10 needed for a value, so it is not shown and is left out of any mean; every other row rests on its own photo count.

Claude: this method was run on 2 of 2 photos, under the 10 needed for a value, so it is not shown and is left out of any mean; every other row rests on its own photo count.

Independent surveys nearby

Data availability near this site
Agency / programYear(s)Stations / distanceLink
Lange et al. (2021)2006–20202 stations, 3.38–4.43 kmRecords ↓
Sheppard et al. (2008)20061 station, 2.21 kmRecords ↓
Spalding et al. (2025)—1 station, 1.42 kmRecords ↓
XL Catlin Seaview Survey20154 stations, 0.66–3.50 kmRecords ↓
Hard coral cover over time — this site and every independent station within 5 km. Programs are shown separately because they use different methods at different stations; the lines are not one comparable series.
0%17%34%51%68%200620132020Sheppard et al. (2008) 2006: 32%Lange et al. (2021) 2006: 29%Lange et al. (2021) 2006: 48%Lange et al. (2021) 2010: 43%Lange et al. (2021) 2010: 63%Lange et al. (2021) 2016: 9.9%Lange et al. (2021) 2018: 6.8%Lange et al. (2021) 2019: 14%Lange et al. (2021) 2019: 23%Lange et al. (2021) 2020: 12%Lange et al. (2021) 2020: 21%XL Catlin Seaview Survey 2015: 22%XL Catlin Seaview Survey 2015: 22%XL Catlin Seaview Survey 2015: 28%XL Catlin Seaview Survey 2015: 28%LOF Global Reef Expedition 2015: 52%Year-averaged across all programs: illustrative only; the programs differ in stations and method, so no trend is claimed (7 years)

Within 5 km, 7 independent survey stations recorded hard coral cover in 19 records between 2006 and 2020. Of the 2 stations surveyed in more than one year, 2 declined (by 17–27 points) between their first and latest surveys. Two stations share the longest span (2006–2020); one, Salomon Atoll (Lange et al. 2021, 3.38 km away), went from 48% in 2006 to 21% in 2020. The most recent nearby survey is from 2020, so these values predate recent heat stress. This site's own estimate (52%) sits 24 points above the range of these station-year means up to 2 km away (22–28%); the methods differ, so the comparison is context, not a like-for-like test. One further row in the table has no survey date, so it is listed but not part of this summary.

Collected by other programs using different methods (the XL Catlin Seaview Survey uses photo-transects with automated image annotation), so these are context for the figures above, not a like-for-like comparison. Where a station was surveyed more than once, the cell shows either the range of its values or, as a single value, the mean of surveys made in one year. Station names are not dive-site names.

Independent survey data near this site
AgencySite / locationDateHard coral cover (%)DistanceLink
Sheppard et al. (2008)Salomon200632% (5 records)2.21 kmdoi:10.3354/meps07436
Lange et al. (2021)Salomon Atoll2006–20206.8–63% (range of yearly means; 5 records)3.38 kmdoi:10.1007/s00338-021-02184-w
Lange et al. (2021)Salomon Atoll2006–20209.9–43% (range of yearly means; 5 records)4.43 kmdoi:10.1007/s00338-021-02184-w
XL Catlin Seaview Surveytransect 36015201528%0.66 kmdoi:10.14264/uql.2019.930
XL Catlin Seaview Surveytransect 36018201522%1.75 kmdoi:10.14264/uql.2019.930
XL Catlin Seaview Surveytransect 36017201522%2.20 kmdoi:10.14264/uql.2019.930
XL Catlin Seaview Surveytransect 36013201528%3.50 kmdoi:10.14264/uql.2019.930
Spalding et al. (2025)Salomon - Boddam Lagoon (N, 1-4 m)pre-bleaching baseline65%1.42 km—

Data & links

All images from Coral Reef Diagnostics. Data are from the Khaled bin Sultan Living Oceans Foundation Global Reef Expedition, Coral Reef Diagnostics, and the organizations named in the data sources above.

© Coral Reef Diagnostics.

References

  1. Mayfield AB, Dempsey AC (2026). Using tourist diver images to estimate coral cover and bleaching prevalence in a remote Indian Ocean coral reef system. Oceans 7(1):1. PDF
  2. Sheppard C, Harris A, Sheppard A (2008). Archipelago-wide coral recovery patterns since 1998 in the Chagos Archipelago, central Indian Ocean. Marine Ecology Progress Series 362:109-117. PDF
  3. Lange ID, Benkwitt CE, McDevitt-Irwin JM, Tietjen KL, Taylor B, Chinkin M, et al. (2021). Wave exposure shapes reef community composition and recovery trajectories at a remote coral atoll. Coral Reefs 40:1819-1829. PDF
  4. Spalding M, Bourasseau M, et al. (2025). Coral bleaching and mortality in the Chagos Archipelago, 2024. British Indian Ocean Territory Administration report (gray literature). PDF
  5. Gonzalez-Rivero M, et al. (2019). Seaview Survey photo-quadrat and image classification dataset. The University of Queensland (UQ eSpace) data collection. DOI
