Reef Check Foundation
Coral Reef Diagnostics

Atauro - Inner Reef

Coral Triangle Center (CTC)
⬇ Download this page as a report card
05
Coral Reef Diagnostics
Photo: Anderson Mayfield/Coral Reef Diagnostics
Survey date(s)
2024-01-30
Coordinates
-8.2195, 125.6120
Approximate position.
Coral cover
45%
Claude computer vision (193 edited photos) · other methods below · median 44%
Observations
Heat stress
Most recent heat load record
26 Oct 2026 · No heat stress
5-year thermal stress load
5-year mean max. degree heating weeks (DHW)
2021–2025
i 5-year mean max. DHW is the mean of the annual maximum DHWs over the five complete years named above, not conditions today.
More infoTimor-Leste (NOAA CRW virtual station)
Photographs
209
21 shown on this page
Site summary
Read this summary in:

A shallow Atauro coral garden with essentially no bare substrate and a broad mix of growth forms: columnar and lobate corals, branching and plating Acropora, mauve bushy branching corals, and big tube-sponge clusters. Two giant clams, one beneath a large maze-patterned brain coral, are wedged into the framework.

Max. depth dived
12.2 m
dive-log maximum
Water temp. during survey
28.1°Cii
-0.9°C vs the 2024 mean sea temperature (29.0°C)
ii Logged water temperature of the dive, January 2024 (dive log); the dive computer's minimum was 27.2°C.
Bottom time
57 min
in at 14:32

Twelve independent survey stations shown with the program’s logo — click one to see how far it is from this site.

Eight other CRD dive sites with their own pages within 5 km shown in orange — click a marker to open its page.

5 of the 21 photographs on this page are shown beside the text that discusses them under "Site description" below.

567891011121314151617181920

Photo credit & attribution

Site description

General benthic features

The first photograph is a coral garden with essentially no bare substrate: thick blunt-fingered columnar colonies in gray-brown and lavender, a dense brown corymbose Acropora mound, cream and lilac digitate and corymbose colonies, a mauve-purple corymbose colony in the near corner, pale yellow-green massive lobate corals and dark lobate heads behind, and — on the right margin — a cluster of orange-brown tube sponges with red interiors (e.g., Image 1).

The second wide frame is a shallower, brighter field of bushy cream and tan branching Acropora running to a blue horizon, with a large brown tube-sponge complex mid-frame, two black feather stars, maroon algal turf and coralline in the interstices, a butterflyfish, an orange-and-dark anemonefish-type damselfish, and dozens of chromis and a surgeonfish silhouetted in the water above (e.g., Image 2).

Across the gallery photographs: high living cover, strong fine- and coarse-scale relief, abundant crustose coralline algae, and no disease lesion or predation scar visible. A computer-vision point count called 1.6% of coral points bleached (13 of 193 photos). Sand, rubble, and pale hardground remain visible in channels between coral outcrops. The repeated wide views show locally high living-coral cover and substantial fine- and coarse-scale structural complexity.

Coral cover

Stressors

The selections do not show a conspicuous site-wide bleaching pattern, but pale-to-white patches and small dead or overgrown lesions recur across roughly a fifth of the reviewed frames (a count that takes pale patches and lesions together; the computer-vision count, which scores bleaching alone, found it in 13 of 193 photos, 6.7%) — more than an isolated occurrence, though still short of a uniform reef-wide signal. The photographs also document a large giant clam embedded among the living coral (e.g., Image 3, Image 4), and a crown-of-thorns seastar was photographed on this dive (e.g., Image 21).

A fouled, algae-encrusted rope lay draped over the top of a large brown massive colony and hung down its face, a derelict line (photo not shown).

Fish and other fauna

A black-and-yellow butterflyfish crosses the frame and small dark damselfishes shelter in the branches (e.g., Image 1). The two close frames among the four reviewed in detail both feature giant clams (Tridacna sp., fluted shells) wedged into the framework: one with a mottled cream-and-black mantle beneath a large maze-patterned brain coral, the other with a dark blue-green striated mantle and a gaping siphon, flanked by a large cream-tentacled sea anemone that shelters a small anemonefish, with fine-corallite massive corals to one side and pale pink verrucose branching colonies above (e.g., Image 3, Image 4).

Comparisons with other data

We found no other surveys at this site as of 2026. Within 5 km, twelve independent stations recorded station-year means of 13–65% hard coral cover between 2004 and 2017; the nearest, Coral Triangle Center (CTC) at Beloi (10), 0.77 km away, read 49% in 2017.

Dive record

Inner Reef was dived on 30 January 2024, a shallow profile to 12.2 m maximum and 6.4 m average.

Other notes

The two wide frames among the four reviewed in detail show dense cover and many growth forms.

CV model comparison

Mean 45%, median 44% across 193 photos.
More infoA few colony-focused photos raise the mean; the median is the typical photo. No computer-vision method yet estimates coral cover accurately on new images, so treat this as indicative rather than a measurement; it is revised as the methods improve.
Headline: Claude computer vision — a blind point count of this site's own photographs.
More infoDINOv3 and CoralSCOP were run on the same photos and are listed for comparison. No diver transect exists for this trip, so agreement between the rows is not accuracy, and no computer-vision method yet estimates coral cover accurately on new images; treat every row as indicative.
MethodHard coral cover (%)Photos (n) ± SE
In-house DINOv338.4n = 193 · SE 0.7
CoralSCOP edited52.6n = 193 · SE 1.4
Claude (edited photos)44.6n = 193 · SE 1.5

The two computer-vision methods disagree by 14.2 pp (38.4–52.6%) and read on both sides of Claude's blind point count (44.6%); the headline is Claude's blind point count because no transect or manual count exists here.

Independent surveys nearby

Data availability near this site
Agency / programYear(s)Stations / distanceLink
Coral Triangle Center (CTC)20173 stations, 0.77–3.60 kmRecords ↓
Reef Check2004–20176 stations, 0.86–4.68 kmRecords ↓
XL Catlin Seaview Survey20143 stations, 0.78–4.94 kmRecords ↓
Hard coral cover over time — this site and every independent station within 5 km. Programs are shown separately because they use different methods at different stations; the lines are not one comparable series.
0%17%34%51%68%200420142024Reef Check 2004: 33%Reef Check 2004: 44%Reef Check 2017: 39%Reef Check 2017: 49%Reef Check 2017: 53%Reef Check 2017: 65%XL Catlin Seaview Survey 2014: 13%XL Catlin Seaview Survey 2014: 17%XL Catlin Seaview Survey 2014: 21%Coral Triangle Center (CTC) 2017: 36%Coral Triangle Center (CTC) 2017: 41%Coral Triangle Center (CTC) 2017: 49%Coral Reef Diagnostics 2024: 45%Year-averaged across all programs: illustrative only; the programs differ in stations and method, so no trend is claimed (4 years)
Reef Check XL Catlin Seaview Survey Coral Triangle Center (CTC) Coral Reef DiagnosticsYear-average (illustrative only, programs differ)

Within 5 km, 12 independent survey stations recorded hard coral cover in 15 surveys between 2004 and 2017. The most recent nearby survey is from 2017, so these values predate recent heat stress. This site's own estimate (45%) sits within the range of these station-year means up to 2 km away (17–65%); the methods differ, so the comparison is context, not a like-for-like test.

Collected by other programs using different methods (Reef Check uses point-intercept transects; the XL Catlin Seaview Survey uses photo-transects with automated image annotation), so these are context for the figures above, not a like-for-like comparison. Where a station was surveyed more than once, the cell shows either the range of its values or, as a single value, the mean of surveys made in one year. Station names are not dive-site names.

Show all 15 independent surveys
Independent survey data near this site
AgencySite / locationDateHard coral cover (%)DistanceLink
Reef CheckSouth of Tanjung Reta200433%, mean of 2 surveys (5.8 m and 12 m)2.92 km—
Reef CheckNorth of Tanjung Reta200444%, mean of 2 surveys (7.1 m and 13 m)4.68 km—
XL Catlin Seaview Surveytransect 30015201421%0.78 kmdoi:10.14264/uql.2019.930
XL Catlin Seaview Surveytransect 30014201417%1.42 kmdoi:10.14264/uql.2019.930
XL Catlin Seaview Surveytransect 30013201413%4.94 kmdoi:10.14264/uql.2019.930
Coral Triangle Center (CTC)Beloi (10)201749%0.77 kmCurrier K, Marine P, Welly M. 2017. Atauro Island MPA. MERMAID
Reef CheckHaru ina201753%, mean of 2 surveys (9 m and 16 m)0.86 km—
Coral Triangle Center (CTC)Outer Reef (09)201741%0.93 kmCurrier K, Marine P, Welly M. 2017. Atauro Island MPA. MERMAID
Reef CheckRai keta tungu201765%1.44 km—
Reef CheckWatu ai201749%2.11 km—
Reef CheckRai keta rala201739%2.11 km—
Coral Triangle Center (CTC)Vila (11)201736%3.60 kmCurrier K, Marine P, Welly M. 2017. Atauro Island MPA. MERMAID
